Kennametal - A4SC, Right Hand Cut, 1.063" Max Workpc Diam, A4..15.. Insert, Indexable Cutoff Toolholder - 0.532 Max Depth of Cut, 16mm Shank Width, 16mm Shank Height, 114mm OAL
Item #: 54126107
Brand: Kennametal
Model #: 2981195
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.5320 |
| Maximum Workpiece Diameter (Decimal Inch) | 1.0630 |
| Series | A4 |
| Toolholder Style | A4SC |
| Insert Compatibility | A4..15.. |
| Overall Length (mm) | 114.00 |
| Overall Length (Decimal Inch) | 4.4882 |
| Shank Width/Diameter (mm) | 16.00 |
| Shank Width/Diameter (Decimal Inch) | 0.6299 |
| Shank Height (mm) | 16.00 |
| Shank Height (Decimal Inch) | 0.6299 |
| Insert Seat Size | 1 |
| Insert Holding Method | Screw |
| Through Coolant | No |
| Minimum Insert Width (mm) | 1.50 |
| Minimum Insert Width (Decimal Inch) | 0.0591 |
| Insert Width (mm) | 1.50 |
| Insert Width (Decimal Inch) | 0.0591 |
| Back of Bar to Cutting Edge (mm) | 15.17 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.5972 |
| Head Height (mm) | 21.00 |
| Head Height (Decimal Inch) | 0.8268 |
| Head Length (mm) | 25.00 |
| Head Length (Decimal Inch) | 0.9843 |
| Shank Length (mm) | 102.00 |
| Shank Length (Decimal Inch) | 4.0157 |
