Walter - INGD3062 Grade IC807, 1/16" Cutting Width, Carbide Grooving Insert - TiAlN/TiN Finish, 3.05mm Depth of Cut, Right Hand, 0.19mm Corner Radius
Item #: 53081899
Brand: Walter
Model #: 6411983
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | INGD |
| Insert Size | 3062 |
| Material | Carbide |
| Cutting Width (mm) | 1.57 |
| Cutting Width (Decimal Inch) | 0.0620 |
| Maximum Depth of Cut (mm) | 3.05 |
| Maximum Depth of Cut (Decimal Inch) | 0.1200 |
| Material Grade | Submicron |
| Manufacturer's Grade | IC807 |
| Coating | TiAlN/TiN |
| Insert Hand | Right Hand |
| Multi-Use Application | Grooving; Parting; Turning |
| Maximum Corner Radius (Decimal Inch) | 0.0075 |
| Corner Radius (mm) | 0.19 |
| Corner Radius (Decimal Inch) | 0.0075 |
| Coating Process | PVD |
| Overall Length (mm) | 22.60 |
| Overall Length (Decimal Inch) | 0.8900 |
| Series | Notch-Grip |
| ISO Number | INGD3062R IC807 |
| Manufacturers Catalog Number | 6411983 |
| Overall Width (mm) | 4.95 |
| Overall Width (Decimal Inch) | 0.1950 |
| Insert Thickness (Decimal Inch) | 0.3440 |
| Insert Thickness (mm) | 8.7400 |
| Thickness (Inch) | 3/16 |
| Shape | Trigon |
| Thickness (Decimal Inch) | 0.1875 |
| Series | Tiger-tec Silver |
| Maximum Depth of Cut (mm) | 5.00 |
| Rake | Negative |
| Maximum Depth of Cut (Decimal Inch) | 0.1969 |
| Material | Carbide |
| Material Grade | K10/H30 |
| Manufacturer's Grade | WKK10S |
| Insert Style | WNMA |
| Insert Size | 432 |
| Insert Holding Method | Pin & Clamp |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Hole Diameter (Decimal Inch) | 0.2020 |
| Corner Radius (Inch) | 1/32 |
| Coating Process | CVD |
| Coating | TiCN/Al2O3/TiCN |
| Corner Radius (Decimal Inch) | 0.0313 |
| Chip Breaker | RK5 |
| Included Angle | 80 |
| Relief Angle | 0 |
| Primary Workpiece Material | K |
| Secondary Workpiece Material | H |
| Single/DoubleEnd | Double |
| Multi Use Application | Turning |
| MultiUseTool | Yes |
