Walter - GIPY6.00-3.00 Grade IC804, 6mm Cutting Width, Carbide Grooving Insert - AlTiN Finish, 3mm Corner Radius
Item #: 53081840
Brand: Walter
Model #: 6411649
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | GIPY |
| Insert Size | 6.00-3.00 |
| Material | Carbide |
| Cutting Width (mm) | 6.00 |
| Cutting Width (Decimal Inch) | 0.2360 |
| Material Grade | Submicron |
| Manufacturer's Grade | IC804 |
| Coating | AlTiN |
| Relief Angle | 7 |
| Multi-Use Application | Grooving; Parting; Turning |
| Maximum Corner Radius (Decimal Inch) | 0.1180 |
| Corner Radius (mm) | 3.00 |
| Corner Radius (Decimal Inch) | 0.1180 |
| Coating Process | PVD |
| Series | Cut Grip |
| ISO Number | GIPY 6.00-3.00 IC804 |
| Manufacturers Catalog Number | 6411649 |
| Overall Width (mm) | 5.00 |
| Overall Width (Decimal Inch) | 0.1970 |
| Thickness (Inch) | 3/16 |
| Shape | Square |
| Thickness (Decimal Inch) | 0.1875 |
| Series | Tiger-tec Silver |
| Maximum Depth of Cut (mm) | 5.00 |
| Rake | Negative |
| Maximum Depth of Cut (Decimal Inch) | 0.1969 |
| Material | Carbide |
| Material Grade | K10/H30 |
| Manufacturer's Grade | WKK10S |
| Insert Style | SNMA |
| Insert Size | 432 |
| Insert Holding Method | Pin & Clamp |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Hole Diameter (Decimal Inch) | 0.2020 |
| Corner Radius (Inch) | 1/32 |
| Coating Process | CVD |
| Coating | TiCN/Al2O3/TiCN |
| Corner Radius (Decimal Inch) | 0.0313 |
| Chip Breaker | RK5 |
| Included Angle | 90 |
| Relief Angle | 0 |
| Primary Workpiece Material | K |
| Secondary Workpiece Material | H |
| Single/DoubleEnd | Double |
| Multi Use Application | Turning |
| MultiUseTool | Yes |
