Iscar - Arbor Hole Connection, 4.685" Depth of Cut, 350mm Cutter Diam, 1.9685" Hole Diam, 26 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSFN Insert
Item #: 52734118
Brand: Iscar
Model #: 2301198
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Maximum Depth of Cut (mm) | 119.00 |
| Maximum Depth of Cut (Decimal Inch) | 4.6850 |
| Cutter Diameter (mm) | 350.00 |
| Cutter Diameter (Decimal Inch) | 13.7795 |
| Hole Diameter (mm) | 50.00 |
| Hole Diameter (Decimal Inch) | 1.9685 |
| Number of Teeth | 26 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSFN |
| Staggered Tooth | No |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 230 |
| Minimum Cutting Width (Decimal Inch) | 0.2169 |
| Maximum Cutting Width (Decimal Inch) | 0.2559 |
| Maximum Cutting Width (mm) | 6.50 |
| Hub Diameter (mm) | 110.00 |
| Hub Diameter (Decimal Inch) | 4.3307 |
