Iscar - 1" Cut Diam, 0.38" Max Depth of Cut, 1" Shank Diam, 3-3/4" OAL, Indexable Square Shoulder End Mill - S/Q/XPM. 1004.-HQ Inserts, Weldon Shank, 90° Lead Angle, Series Heliquad
Item #: 52707965
Brand: Iscar
Model #: 3110443
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 1.0000 |
| Cutting Diameter (Inch) | 1 |
| Shank Type | Weldon |
| Shank Diameter (Inch) | 1 |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Overall Length/Projection (Inch) | 3-3/4 |
| Overall Length/Projection (Decimal Inch) | 3.7500 |
| Lead Angle | 90 |
| Series | Heliquad |
| Through Coolant | Noncoolant Through |
| Maximum Depth of Cut (Decimal Inch) | 0.3800 |
| Number of Cutter Inserts | 2 |
| Insert Holding Method | Screw |
| End Mill Type | End Mill |
| Cutter Style | E90SP |
| Number of Flutes | 2 |
| Head Length (Inch) | 1-1/4 |
| Head Length (Decimal Inch) | 1.2500 |
| Weldon Flat | Yes |
| Insert Compatibility | S/Q/XPM. 1004.-HQ |
| Shank Length (Inch) | 2-1/2 |
| Shank Length (Decimal Inch) | 2.5000 |
| Maximum RPM | 7000 |
