Iscar - 3mm to 26mm Capacity, 64mm Projection, Modular Connection, ER40 Collet Chuck - Through-Spindle
Item #: 52694890
Brand: Iscar
Model #: 4550200
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Collet System | ER |
| Collet Series | ER40 |
| Shank Type | Modular Connection |
| Modular Connection Size | MB63 |
| Projection (mm) | 64.00 |
| Projection (Decimal Inch) | 2.5197 |
| Through Coolant | Yes |
| Minimum Collet Capacity (Decimal Inch) | 0.1181 |
| Minimum Collet Capacity (mm) | 3.00 |
| Maximum Collet Capacity (mm) | 26.00 |
| Maximum Collet Capacity (Decimal Inch) | 1.0236 |
| Nose Diameter (mm) | 63.00 |
| Nose Diameter (Decimal Inch) | 2.4803 |
| PSC Code | 5136 |
| Coolant Type | Through-Spindle |
