KIPP - 1/4-20, 20mm Thread Length, 2.5mm Plunger Projection, Steel Threaded Spring Plunger - 2.7mm Max Plunger Diam, 20mm Plunger Length, 7 N Init End Force, 20 N Final End Force, 5/64" Hex
Item #: 52252467
Brand: KIPP
Model #: K0318.A2
Exact Tooling IR#: 04
Features and Benefits
Plastic is a durable, high-strength and abrasive resistant material used in a variety of general purpose applications.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Thread Size | 1/4-20 |
| Thread Length (Decimal Inch) | 0.7874 |
| Thread Length (mm) | 20.00 |
| Nose Material | Plastic |
| Body Material | Steel |
| Maximum Plunger Diameter (mm) | 2.70 |
| Maximum Plunger Diameter (Decimal Inch) | 0.1063 |
| Plunger Projection (mm) | 2.50 |
| Plunger Projection (Decimal Inch) | 0.0984 |
| Locking Element | No |
| Body Length (mm) | 20.00 |
| Body Length (Decimal Inch) | 0.7874 |
| Plunger Length (mm) | 20.00 |
| Plunger Length (Decimal Inch) | 0.7874 |
| Final End Force (N) | 20.00 |
| Initial End Force (N) | 7.00 |
| Hex Size (Inch) | 5/64 |
| Hex Size (Decimal Inch) | 0.0781 |
| Finish/Coating | Black Oxide |
| Installation Type | Hexagon Socket |
