KIPP - 8-36, 15mm Thread Length, 1.5mm Plunger Projection, Steel Threaded Spring Plunger - 1.5mm Max Plunger Diam, 15mm Plunger Length, 5 N Init End Force, 16 N Final End Force, 0.05" Hex
Item #: 52251907
Brand: KIPP
Model #: K0317.AG
Exact Tooling IR#: 04
Features and Benefits
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Thread Size | 8-36 |
| Thread Length (Decimal Inch) | 0.5906 |
| Thread Length (mm) | 15.00 |
| Nose Material | Steel |
| Body Material | Steel |
| Maximum Plunger Diameter (mm) | 1.50 |
| Maximum Plunger Diameter (Decimal Inch) | 0.0591 |
| Plunger Projection (mm) | 1.50 |
| Plunger Projection (Decimal Inch) | 0.0591 |
| Locking Element | No |
| Body Length (mm) | 15.00 |
| Body Length (Decimal Inch) | 0.5906 |
| Plunger Length (mm) | 15.00 |
| Plunger Length (Decimal Inch) | 0.5906 |
| Final End Force (N) | 16.00 |
| Initial End Force (N) | 5.00 |
| Hex Size (Decimal Inch) | 0.0500 |
| Finish/Coating | Black Oxide |
| Installation Type | Hexagon Socket |
