KIPP - M5, 3mm Ball Diam, 12mm Body Length, 0.9mm Max Ball Reach, Threaded Ball Plunger - Steel Body, Steel Ball, 19 N Initial End Force, 30 N Final End Force, Locking Element
Item #: 52203403
Brand: KIPP
Model #: K0321.205
Exact Tooling IR#: 04
Features and Benefits
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
Steel balls are strong and durable, but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Thread Size | M5 |
| Body Length (mm) | 12.00 |
| Body Length (Decimal Inch) | 0.4724 |
| Body Material | Steel |
| Ball Material | Steel |
| Initial End Force (N) | 19.00 |
| Final End Force (N) | 30.00 |
| Locking Element | Yes |
| Ball Diameter (Decimal Inch) | 0.1181 |
| Ball Diameter (mm) | 3.00 |
| Finish/Coating | Black Oxide |
| Installation Type | Slotted |
| Maximum Ball Reach (mm) | 0.90 |
| Maximum Ball Reach (Decimal Inch) | 0.0354 |
