KIPP - 16mm Body Length x 12mm Body Diam, 15 N Init to 25 N Final End Force, Stainless Steel Press-Fit Ball Plungers - 3.3mm Max Ball Reach, 2.5mm Flange Thickness
Item #: 52154507
Brand: KIPP
Model #: K0333.312
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (mm) | 12.00 |
| Body Length (Decimal Inch) | 0.6299 |
| Body Length (mm) | 16.00 |
| Body Material | Stainless Steel |
| Ball Material | Stainless Steel |
| Maximum Ball Reach (mm) | 3.30 |
| Maximum Ball Reach (Decimal Inch) | 0.1299 |
| Initial End Force (N) | 15.00 |
| Initial End Force (Lb.) | 3.37 |
| Final End Force (N) | 25.00 |
| Final End Force (Lb.) | 5.62 |
| Length Under Flange (mm) | 13.50 |
| Flange Diameter (mm) | 14.00 |
| Flange Thickness (mm) | 2.50 |
