Climax Metal Products - M5 Thread, 22mm Bore Diam, 1-9/16" OD, Shaft Locking Device - 6 Screws, 5,277 Lb Axial Load, 1-3/4" OAW, 0.591" Thrust Ring Width, 2,285 Ft/Lb Max Torque
Item #: 51320901
Brand: Climax Metal Products
Model #: C193M-22
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M5 |
| Bore Diameter (mm) | 22.000 |
| Outside Diameter (Decimal Inch) | 1.5630 |
| Thrust Ring Width (Decimal Inch) | 0.591 |
| Overall Width (Decimal Inch) | 1.7500 |
| Axial Load Lbs (Pounds) | 5277 |
| Maximum Torque (Ft/Lb) | 2285 |
| Number of Screws | 6.000 |
| Contact Pressure on Hub (psi) | 15159.000 |
| Contact Pressure on Shaft (psi) | 27347.000 |
| Screw Seating Torque (In/Lb) | 1068.000 |
