Indexable Turning Toolholder: PWLNR1233, 95.000 deg Lead Angle, Lever
Item #: 13650023
Brand: Tungaloy
Model #: 6711297
Product Specifications
| Toolholder Style | PWLN |
| Hand of Holder | Right Hand |
| Lead Angle | 95.000 |
| Insert Compatibility | WN..33. |
| Insert Holding Method | Lever |
| Shank Width (Inch) | 3/4 |
| Shank Height (Inch) | 3/4 |
| Overall Length (Decimal Inch) | 4.5000 |
| Rake | Negative |
| Cutting Direction | Right Hand |
| Compatible Insert Size Code | WN..33. |
| Multi-use Tool | Yes |
| Shank Width (Decimal Inch) | 0.7500 |
| Shank Height (Decimal Inch) | 0.7500 |
| Series | PWLN |
| Overall Length (Inch) | 4-1/2 |
| Cutting Tool Application | Facing; Turning |
| Head Length (Decimal Inch) | 0.6250 |
| Back of Bar to Cutting Edge (Inch) | 1 |
| Primary Workpiece Material | Universal |
| Insert Inscribed Circle (Inch) | 3/8 |
| Toolholder Material | Steel |
| UNSPSC Code | 23153308 |
| Insert Thickness (Decimal Inch) | 0.1560 |
