Profiling Insert: RCMK46 KCU10B, .654" Thick, 1/2" Inscribed Circle
Item #: 82161126
Brand: Kennametal
Model #: 7096368
Product Specifications
| Insert Style | RCMK |
| Insert Size Code | 152 |
| Insert Material | Carbide |
| Manufacturer Grade | KCU10B |
| Thickness (Inch) | .654 |
| Insert Height (Decimal Inch) | 0.6540 |
| Thickness (mm) | 16.6100 |
| Insert Height (mm) | 16.61 |
| Maximum Depth of Cut (Decimal Inch) | 0.2500 |
| Maximum Depth of Cut (mm) | 6.35 |
| Insert Holding Method | Pin |
| Insert Hand | Neutral |
| Corner Radius (Decimal Inch) | 0.2500 |
| Corner Radius (mm) | 6.35 |
| Included Angle | 0.00 |
| Relief Angle | 7.500 |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (mm) | 12.70 |
| Coating Process | PVD |
| Number Of Cutting Edges | 6 |
| Iso Code | RCMK120800 |
| Rake Angle | 7.500 |
| Coating/Finish | AlTiN |
| Thickness (Decimal Inch - 4 Decimals) | 0.6540 |
| Width (Decimal Inch - 4 Decimals) | 0.6660 |
| Width (mm - 2 Decimals) | 16.61 |
| UNSPSC Code | 23242105 |
