Kyocera - TKFB16 GQ Grade PR1225 Carbide Turning Insert - Megacoat Finish, 60° Triangle, 4mm Thick, 0.1499mm Corner Radius
Item #: 50456128
Brand: Kyocera
Model #: 8844284
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TKFB |
| Insert Size | 16 |
| Material | Carbide |
| Thickness (Decimal Inch) | 0.1575 |
| Thickness (mm) | 4.00 |
| Corner Radius (mm) | 0.1499 |
| Corner Radius (Decimal Inch) | 0.0059 |
| Manufacturer's Grade | PR1225 |
| Coating | Megacoat |
| Material Grade | Micrograin |
| Chip Breaker | GQ |
| Hole Diameter (mm) | 5.20 |
| Hole Diameter (Decimal Inch) | 0.2047 |
| Rake | Positive |
| Rake Angle | 5 |
| Coating Process | PVD |
| Manufacturers Catalog Number | TKFB16R38015GQ PR1225 |
| Primary Workpiece Material | M |
| Included Angle | 60 |
| Cutting Direction | Right Hand |
| Insert Hand | Right Hand |
| Insert Holding Method | Screw |
| Multi Use Application | Turning |
| MultiUseTool | No |
| Shape | Triangle |
