Kyocera - 8 Inserts, 32mm Cut Diam, 8.5mm Arbor Diam, 6mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 40mm High, BDMT 0703 Insert Compatibility, Through Coolant
Item #: 50389774
Brand: Kyocera
Model #: 8822927
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 32.00 |
| Cutting Diameter (Decimal Inch) | 1.2598 |
| Arbor Hole Diameter (mm) | 8.50 |
| Arbor Hole Diameter (Decimal Inch) | 0.3346 |
| Lead Angle | 0 |
| Overall Height (mm) | 40.00 |
| Overall Height (Decimal Inch) | 1.5748 |
| Insert Compatibility | BDMT 0703 |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 6.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.2362 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 8 |
| Insert Holding Method | Screw |
| Cutter Style | MECX |
| Number of Flutes | 8 |
| Cutting Rake Angle | -9 |
| Rake | Negative |
| Hub Diameter (mm) | 30.00 |
| Hub Diameter (Decimal Inch) | 1.1811 |
| Keyway Width (mm) | 8.50 |
| Keyway Width (Decimal Inch) | 0.3346 |
| Keyway Depth (Decimal Inch) | 0.216535 |
| Keyway Depth (mm) | 5.50 |
| Maximum RPM | 33600 |
| Pitch | Extra Fine |
| ISO Number | MECX032R-07-8T-M |
| Complete Insert Compatibility | BDMT 070302ER-JS; BDMT 070302ER-JT; BDMT 070304ER-JS; BDMT 070304ER-JT; BDMT 070308ER-JS; BDMT 070308ER-JT |
