Iscar - 1.87, 1.92, 2.01" Cut Diam, 3/4" Arbor Hole, 2.5mm Max Depth of Cut, 42° Indexable Chamfer & Angle Face Mill - 4 Inserts, OE.. 060405\xB6OEMW 060405-AETN\xB6REMT 1505-LM-76 Insert, Right Hand Cut, 4 Flutes, Through Coolant, Series Heliocto
Item #: 50067131
Brand: Iscar
Model #: 3106593
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 1.8700; 1.9200; 2.0100 |
| Arbor Hole Diameter (Decimal Inch) | 0.7500 |
| Lead Angle | 42 |
| Overall Height (Decimal Inch) | 1.7500; 1.7700; 1.8000 |
| Insert Compatibility | OE.. 060405; OEMW 060405-AETN; REMT 1505-LM-76 |
| Series | Heliocto |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 2.50 |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutter Style | HOF |
| Number of Flutes | 4 |
| Hub Diameter (Decimal Inch) | 1.8100 |
| Keyway Width (Decimal Inch) | 0.3120 |
| Cutting Direction | Right Hand |
| Cutting Edge Length (Decimal Inch) | 0.5100 |
| Counterbore Diameter (Decimal Inch) | 0.6300 |
| Complete Insert Compatibility | OECR 060405AER; OECR 060405AER-P; OEKT 060405AER; OEMT 060405AER-76; OEMW 060405-AETN; REMT 1505-LM-76; SEMT 140405ATR |
