Schneider Electric - 110-120 V at 50/60 Hz Green Lens Incandescent Push-to-Test Pilot Light - Domed/Round Lens, Screw Connector, 3.37" OAL x 0.84" Wide, Dust-tight, Oiltight, Shock Resistant, Vibration Resistant, Watertight
Item #: 49948300
Brand: Schneider Electric
Model #: 9001JT1G29
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Pilot/Indicator Light Type | Push-to-test Pilot Light |
| Lamp Type | Incandescent |
| Lens Color | Green |
| Connector Type | Screw |
| Resistance Features | Dust-tight; Oiltight; Shock Resistant; Vibration Resistant; Watertight |
| Voltage | 110-120 V @ 50/60 Hz |
| Overall Length (Decimal Inch) | 3.37 |
| Overall Width/Diameter (Decimal Inch) | 0.84 |
| Replacement Lamp | 755 |
| Panel Cut Out Diameter (mm) | 17-1/2 |
| Panel Cut Out Diameter (Decimal Inch) | 0.68 |
| Lens Shape | Domed; Round |
| Standards Met | CE Marked; CSA File No. 25490 Class 3211 03; IEC337-2 NF C 63-140; RoHS Compliant; UL File No. E42259 CCN NKCR; VDE 0660-200 |
