Schneider Electric - 1.22 Inch Mount Hole, 3 Position, Knob Operated, Selector Switch with Contact Blocks - Black, Maintained (MA), Nonilluminated, 4 Contact Blocks, 2NO/2NC, Dusttight, Oiltight, Watertight, Shock and Vibration Resistant
Item #: 49764095
Brand: Schneider Electric
Model #: 9001KS43BH12
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Mounting Hole Diameter (mm) | 31 |
| Mounting Hole Diameter (Decimal Inch) | 1.2200 |
| Selector Switch Type | Selector Switch with Contact Blocks |
| Operator Type | Knob |
| Number of Positions | 3 |
| Operation Type | Maintained (MA) |
| Operator Color | Black |
| Terminal Type | Screw Clamp |
| Contact Configuration | 2NO/2NC |
| Voltage | 600 VAC/VDC |
| Amperage | 10 |
| Number of Contact Blocks | 4 |
| Cam Code | C |
| Operator Illumination | NonIlluminated |
| Bezel Material | Metal |
| Bezel Color | Chrome |
| Head Shape | Round |
| Mounting Type | Panel Mount |
| Mounting Orientation | Horizontal; Vertical |
| Resistance Features | Dust-tight; Oiltight; Shock Resistant; Vibration Resistant; Watertight |
| Ingress Protection Rating | IP20 (Terminal); IP65; IP66 |
| NEMA Rating | 1; 2; 3; 4; 6; 12; 13; 3R |
| Standards Met | CE Certified; CSA C22.2 No. 14; CSA Certified File No. LR25490 Class 3211 03; CSA Certified File No. LR26817 Class 3218 02; CSA File No. LR24590 Class 3211-03; EN/IEC 60947-1; EN/IEC 60947-5-1; EN/IEC 60947-5-4; JIS C 4520; JIS C 852; RoHS Compliant; UL 5 |
