Sandvik Coromant - CNGX1204 AXA Grade 7025 CBN Turning Insert - Uncoated, 80° Diamond, 1/2" Inscr Circle, 3/16" Thick
Item #: 49453046
Brand: Sandvik Coromant
Model #: 5725208
Exact Tooling IR#: 04
Features and Benefits
Cubic boron nitride (CBN) is similar in hardness to diamond. It is commonly used for machining hardened steel and related alloys at high temperatures.
| Product Specifications | |
|---|---|
| Insert Style | CNGX |
| Insert Size | 1204 |
| Material | CBN |
| Inscribed Circle (mm) | 12.70 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Thickness (Inch) | 3/16 |
| Thickness (Decimal Inch) | 0.1874 |
| Thickness (mm) | 4.76 |
| Manufacturer's Grade | 7025 |
| Coating | Uncoated |
| Chip Breaker | AXA |
| Hole Diameter (mm) | 5.16 |
| Hole Diameter (Decimal Inch) | 0.2032 |
| ISO Number | CNGX1204L02518AXA7025 |
| Relief Angle | 0 |
| Manufacturers Catalog Number | 5725208 |
| Primary Workpiece Material | H |
| Secondary Workpiece Material | H |
| Included Angle | 80 |
| Cutting Direction | Left Hand |
| Insert Hand | Left Hand |
| Series | T-Max P |
| Maximum Depth of Cut (mm) | 0.25 |
| Maximum Depth of Cut (Decimal Inch) | 0.0098 |
| Insert Holding Method | Pin & Clamp |
| Multi Use Application | Turning |
| Shape | Diamond |
