Sandvik Coromant - 128mm Max Drill Depth, 4xD, 31mm Diam, Indexable Insert Drill - 2 Inserts, C6 Modular Connection Shank
Item #: 49334063
Brand: Sandvik Coromant
Model #: 5765352
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | 880 |
| Drill Diameter (mm) | 31.00 |
| Drill Diameter (Decimal Inch) | 1.2205 |
| Maximum Drill Depth (mm) | 128.00 |
| Maximum Drill Depth (Decimal Inch) | 5.0394 |
| Shank Type | Modular Connection |
| Modular Connection Size | C6 |
| Cutting Direction | Right Hand |
| Through Coolant | Through Coolant |
| Drill Depth by Diameter Ratio | 4xD |
| Toolholder Material | Steel |
| Number of Drill Inserts | 2 |
| Maximum Drill Diameter (Decimal Inch) | 1.2205 |
| Maximum Drill Diameter (mm) | 33.00 |
| Overall Length/Projection (mm) | 212.00 |
| Overall Length/Projection (Decimal Inch) | 8.3465 |
| Insert Compatibility | 880-060406H-C-GM; 880-0604W06H-P-GM |
| Flute Length (mm) | 124.00 |
| Flute Length (Decimal Inch) | 4.8819 |
| Body Length (Decimal Inch) | 6.8284 |
| Body Length (mm) | 173.44 |
| Shank Length (mm) | 38.56 |
| Shank Length (Decimal Inch) | 1.5181 |
| Series | CoroDrill 880 |
| Radial Adjustment (-mm) | 0.99 |
