13/16″ Bore Diam, 13/16″ Nom'l Size, Stainless Steel Internal Snap Retaining Ring 0.901″ Free OD, 0.046″ Groove Width x 0.046″ Groove Depth, 0.042″ Ring Thickness
Item #: 48346795
Brand: Rotor Clip
Model #: HO-81SS
Product Specifications
| Ring Type | Snap |
| System of Measurement | Inch |
| Groove Diameter | 0.862 in |
| Nominal Size (Inch) | 13/16 |
| Bore Diameter (Inch) | 13/16 |
| Bore Diameter (Decimal Inch) | 0.8125 in |
| Groove Diameter Tolerance | -0.0030 to 0.0030 in |
| Free Diameter | 0.901 in |
| Free Outside Diameter | 0.901 in |
| Groove Diameter (Decimal Inch) | 0.8620 |
| Material | Stainless Steel |
| Groove Width (Decimal Inch) | 0.046 in |
| Inside Diameter | 3.01 in |
| Free Outside Diameter (Decimal Inch) | 0.9010 |
| Groove Width Tolerance | -0.000 to 0.003 in |
| Military Specification | Does Not Meet Military Specifications |
| Groove Depth | 0.046 in |
| Ring Thickness (Decimal Inch) | 0.042 in |
| Ring Thickness Tolerance | -0.002 to 0.002 in |
| Thrust Load Capacity | 1710 (Groove Safety Factor) lb; 4872 (Ring Safety Factor) lb |
| Meets Specification | Yes |
| Groove Depth (Decimal Inch) | 0.0460 |
| Inside Diameter (Decimal Inch) | 3.0100 |
| Groove Diameter Tolerance (Decimal Inch) | -0.0030 to 0.0030 |
