Iscar - TPMX2807 RG Grade IC520 Carbide Indexable Drill Insert - TiCN/TiN Finish, Triangle, 17mm Inscribed Circle
Item #: 46683736
Brand: Iscar
Model #: 4800856
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
TiCN/TiN is a multi-layered coating designed to increase tool life. It is commonly used at high cutting speeds for smoothing and finishing of the workpiece.
| Product Specifications | |
|---|---|
| Insert Style | TPMX |
| Insert Size | 2807 |
| Material | Carbide |
| Manufacturer's Grade | IC520 |
| Inscribed Circle (mm) | 17.00 |
| Inscribed Circle (Decimal Inch) | 0.6690 |
| Thickness (mm) | 7.50 |
| Thickness (Decimal Inch) | 0.2950 |
| Corner Radius (mm) | 1.60 |
| Corner Radius (Decimal Inch) | 0.0630 |
| Shape | Triangle |
| Coating | TiCN/TiN |
| Coating Process | PVD |
| Cutting Direction | Right Hand |
| Chipbreaker | RG |
