Iscar - 1.0236" Blade Height, 0.3346" Blade Width, 110mm OAL, Right Hand Cut, Double End Indexable Cut-Off Blade - PCHB Blade, PentaCut Series
Item #: 45371242
Brand: Iscar
Model #: 2302306
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Single or Double End | Double |
| Cutting Direction | Right Hand |
| Blade Height (mm) | 26.00 |
| Blade Height (Decimal Inch) | 1.0236 |
| Blade Width (mm) | 8.50 |
| Blade Width (Decimal Inch) | 0.3346 |
| Blade Overall Length (mm) | 110.00 |
| Blade Style | PCHB |
| Insert Style | PENTA 24N-J; PENTA 24N-J (Full Radius); PENTA 24N-PF; PENTA 24N-Z; PENTA 24R/L-J; PENTA 24R/L-Z |
| Insert Width (mm) | 0.50 |
| Insert Width (Decimal Inch) | 0.0197 |
| Series | PentaCut |
| Insert Holding Method | Screw |
| Cutting Height (mm) | 21.40 |
| Cutting Height (Decimal Inch) | 0.8425 |
| Minimum Insert Width (mm) | 0.50 |
| Minimum Insert Width (Decimal Inch) | 0.0197 |
| Maximum Insert Width (mm) | 6.20 |
| Maximum Insert Width (Decimal Inch) | 0.2440 |
| Complete Insert Compatibility | PENTA..24.. |
| Complete Tool Block/Toolholder Style Compatibility | C..TBK..,HS..TBK..,IM..TBK..,SGT.. |
