Associated Spring Raymond - 3.76mm OD, 0.58mm Wire, 9.65mm Free Length, Compression Spring - 31.7 Lb Spring Rating, 17.97 N Max Work Load, Music Wire
Item #: 44538825
Brand: Associated Spring Raymond
Model #: C01480230380M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.76 |
| Outside Diameter (Decimal Inch) | 0.1480 |
| Free Length (mm) | 9.65 |
| Free Length (Decimal Inch) | 0.3800 |
| Spring Rate Pounds per Inch (Pounds) | 31.7000 |
| Maximum Work Load (N) | 17.96999931 |
| Solid Height (mm) | 5.54 |
| Solid Height (Decimal Inch) | 0.2180 |
| Material | Music Wire |
| Wire Size (mm) | 0.58 |
| Wire Size (Decimal Inch) | 0.0230 |
