De-Sta-Co - 699 Lb Inner Hold Capacity, Vert Mount, Air Power Hold-Down Toggle Clamp - G1/8 Port, 145 Max psi, 88° Bar Opening, 99.31mm Height Under Bar
Item #: 44002780
Brand: De-Sta-Co
Model #: 827-SE
Exact Tooling IR#: 04
Features and Benefits
Vertical mounts are designed with the toggle at 90 degrees. The cylinder is mounted in either a vertical position or a position that is perpendicular to the clamping bar.
| Product Specifications | |
|---|---|
| Power Type | Pneumatic |
| Mounting Orientation | Vertical |
| Holding Capacity - Inner (N) | 3110 |
| Holding Capacity - Inner (Lb.) | 699 |
| Height Under Bar (mm) | 99.31 |
| Height Under Bar (Decimal Inch) | 3.91 |
| Port Size | G1/8 |
| Bar Opening (Degrees) | 88 |
| Width Distance Between Mount Holes (mm) | 31.75 |
| Width Distance Between Mount Holes (Decimal Inch) | 1.2500 |
| Clamping Force - Inner (N) | 2200 |
| Clamping Force - Inner (Lb.) | 495 |
| Overall Open Length (mm) | 134.87 |
| Overall Open Length (Decimal Inch) | 5.31 |
| Overall Closed Length (mm) | 215.65 |
| Overall Closed Length (Decimal Inch) | 8.49 |
| Overall Closed Height (mm) | 229.62 |
| Overall Closed Height (Decimal Inch) | 9.04 |
| Outer Clamping Force (N) | 1257 |
| Outer Clamping Force (Lb.) | 283 |
| Maximum Air Pressure (psig) | 145.00 |
| Maximum Air Pressure (bar) | 10.00 |
| Mounting Hole Size (mm) | 8.38 |
| Mounting Hole Size (Decimal Inch) | 0.3300 |
| Bar Style | Solid |
| Bar End Type | Closed |
| Maximum Mechanical Advantage | 2:1; 3.5:1 |
| Sensor Compatibility | Round; T-Slot |
| Cylinder Bore Size (mm) | 39.88 |
| Cylinder Bore Size (Decimal Inch) | 1.5700 |
| Maximum Operating Temperature (C) | 90.00 |
| Maximum Operating Temperature (F) | 194.00 |
| Minimum Operating Temperature (F) | 14.00 |
| Minimum Operating Temperature (C) | -10.00 |
| Includes | Bolt Retainer |
