Kennametal - Insert Style LT 27NL, 60mm Head Length, Left Hand Cut, Internal Modular Threading Cutting Unit Head - System Size KM63TS, 43mm Center to Cutting Edge, Series LT Threading
Item #: 42681460
Brand: Kennametal
Model #: 3959386
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| System Size | KM63TS |
| Series Name | LT Threading |
| Thread Type | Internal |
| Cutting Direction | Left Hand |
| Center to Cutting Edge (mm) | 43.00 |
| Center to Cutting Edge (Decimal Inch) | 1.6929 |
| Head Length/Projection (mm) | 60.00 |
| Head Length/Projection (Decimal Inch) | 2.3622 |
| Insert Style | LT 27NL |
| Insert Holding Method | Screw |
| Minimum Hole Diameter (mm) | 86.00 |
| Minimum Hole Diameter (Decimal Inch) | 3.3858 |
| Maximum Hole Depth (mm) | 60.00 |
| Maximum Hole Depth (Decimal Inch) | 2.3622 |
