De-Sta-Co - 200 Lb Inner Hold Capacity, Horiz Mount, Air Power Hold-Down Toggle Clamp - G1/8 Port, 145 Max psi, 102° Bar Opening, 26.92mm Height Under Bar
Item #: 42148734
Brand: De-Sta-Co
Model #: 802-UE
Exact Tooling IR#: 04
Features and Benefits
Horizontal mounts indicate that the cylinder is mounted parallel to the clamping bar's closed position.
| Product Specifications | |
|---|---|
| Power Type | Pneumatic |
| Mounting Orientation | Horizontal |
| Holding Capacity - Inner (N) | 890 |
| Holding Capacity - Inner (Lb.) | 200 |
| Height Under Bar (mm) | 26.92 |
| Height Under Bar (Decimal Inch) | 1.06 |
| Port Size | G1/8 |
| Bar Opening (Degrees) | 102 |
| Length Distance Between Mount Holes (mm) | 12.70 |
| Length Distance Between Mount Holes (Decimal Inch) | 0.5000 |
| Width Distance Between Mount Holes (mm) | 26.92 |
| Width Distance Between Mount Holes (Decimal Inch) | 1.0600 |
| Clamping Force - Inner (N) | 2010 |
| Clamping Force - Inner (Lb.) | 452 |
| Bar Extension (Decimal Inch) | 1.7300 |
| Bar Extension (mm) | 43.94 |
| Overall Closed Length (mm) | 195.33 |
| Overall Closed Length (Decimal Inch) | 7.69 |
| Overall Open Height (Decimal Inch) | 3.77 |
| Overall Open Height (mm) | 95.76 |
| Overall Closed Height (mm) | 64.77 |
| Overall Closed Height (Decimal Inch) | 2.55 |
| Outer Clamping Force (N) | 1045 |
| Outer Clamping Force (Lb.) | 235 |
| Maximum Air Pressure (psig) | 145.00 |
| Maximum Air Pressure (bar) | 10.00 |
| Mounting Hole Size (mm) | 5.59 |
| Mounting Hole Size (Decimal Inch) | 0.2200 |
| Bar Style | Solid |
| Bar End Type | Closed |
| Maximum Mechanical Advantage | 2.6:1; 5:1 |
| Sensor Compatibility | Round; T-Slot |
| Cylinder Bore Size (mm) | 32.00 |
| Cylinder Bore Size (Decimal Inch) | 1.2600 |
| Spindle Thread Size | 1/4; M6 |
| Maximum Operating Temperature (C) | 90.00 |
| Maximum Operating Temperature (F) | 194.00 |
| Minimum Operating Temperature (F) | 14.00 |
| Minimum Operating Temperature (C) | -10.00 |
| Includes | Spindle Assembly |
