Coffing - 1/4 Ton Capacity, 16 FPM Lift Speed, 115/230 Volt, Hoist with Motorized Trolley - 0.5 Output hp, 20' Max Lift, 17-15/16" Min Headroom, 1 Chain
Item #: 41836313
Brand: Coffing
Model #: JLCMT0516-1-20
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Hoist w/Motorized Trolley |
| Load Capacity (Ton) | 1/4 |
| Load Capacity (Lb.) | 500 |
| Lifting Speed in Ft/Min | 16 |
| Maximum Lift Distance (Feet) | 20 |
| Lift Speed Type | Single |
| Trolley Speed Type | Single |
| Traversing Speed in Ft/Min | 35 |
| Minimum Headroom (Inch) | 17-15/16 |
| Voltage | 115/230 |
| Number of Chains | 1 |
| Lift Output Horse Power | 0.500 |
| Lift Amperage at 208/230 VAC | 17.0 |
| Lift Motor Phase | Single |
| Traversing Motor Phase | Single |
| Traversing Output Horse Power | 0.25 |
| Traversing Amperage at 208/230 VAC | 2.00 |
| Flange Width Range (Decimal Inch) | 3.33 - 7.00 |
| Controller | Pendant Control |
| Lifting Material | Chain |
