Square D - 60 Amp, 600Y/347 VAC, 3 Pole, Panel Mount B-Frame Circuit Breaker - Thermal-Magnetic Trip, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600Y/347 VAC Breaking Capacity, 14-2/0 AWG
Item #: 41397100
Brand: Square D
Model #: BJA36060
Exact Tooling IR#: 04
Features and Benefits
Thermal-magnetic tripping mechanisms are designed with both a bi-metal switch and an electromagnet. They perform as a thermal breaker for low level overloads and perform as a magnetic breaker for instantaneous tripping mechanism at high levels.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | B-Frame Circuit Breaker |
| Amperage | 60 |
| Number of Poles | 3 |
| Breaking Capacity | 100 kA @ 240 VAC; 65 kA @ 480 VAC; 25 kA @ 600Y/347 VAC |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | I-Line; Lug |
| Mounting Type | Panel Mount |
| Voltage | 600Y/347 VAC |
| Wire Size (AWG) | 14-2/0 |
| Maximum Operating Temperature (F) | 158 |
| Minimum Operating Temperature (F) | -13 |
| Reset Actuator Type | Toggle Switch |
