Square D - 45 Amp, 347 VAC, 1 Pole, Unit Mount B-Frame Circuit Breaker - Thermal-Magnetic Trip, 100 kA at 240 VAC, 25 kA at 347 VAC, 65 kA at 277 VAC Breaking Capacity, 14-3/0 AWG
Item #: 41397027
Brand: Square D
Model #: BJL16045
Exact Tooling IR#: 04
Features and Benefits
Thermal-magnetic tripping mechanisms are designed with both a bi-metal switch and an electromagnet. They perform as a thermal breaker for low level overloads and perform as a magnetic breaker for instantaneous tripping mechanism at high levels.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | B-Frame Circuit Breaker |
| Amperage | 45 |
| Number of Poles | 1 |
| Breaking Capacity | 100 kA @ 240 VAC; 25 kA @ 347 VAC; 65 kA @ 277 VAC |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Lug |
| Mounting Type | Unit Mount |
| Voltage | 347 VAC |
| Wire Size (AWG) | 14-3/0 |
| Maximum Operating Temperature (F) | 158 |
| Minimum Operating Temperature (F) | -13 |
| Reset Actuator Type | Toggle Switch |
