Square D - 50 Amp, 480Y/277 VAC, 3 Pole, Panel Mount B-Frame Circuit Breaker - Thermal-Magnetic Trip, 65 kA at 240 VAC, 35 kA at 480Y/277 VAC Breaking Capacity, 14-2/0 AWG
Item #: 41383647
Brand: Square D
Model #: BGA34050Y
Exact Tooling IR#: 04
Features and Benefits
Thermal-magnetic tripping mechanisms are designed with both a bi-metal switch and an electromagnet. They perform as a thermal breaker for low level overloads and perform as a magnetic breaker for instantaneous tripping mechanism at high levels.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | B-Frame Circuit Breaker |
| Amperage | 50 |
| Number of Poles | 3 |
| Breaking Capacity | 65 kA @ 240 VAC; 35 kA @ 480Y/277 VAC |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | I-Line; Lug |
| Mounting Type | Panel Mount |
| Voltage | 480Y/277 VAC |
| Wire Size (AWG) | 14-2/0 |
| Maximum Operating Temperature (F) | 158 |
| Minimum Operating Temperature (F) | -13 |
| For Use With | Overload and Short Circuit Protection |
| Standards Met | UL 489; CSA C22.2 No. 5; NMX J-266; IEC/EN 60947-2; IEC/EN60947-5-1; GB 14048.2; NOM; CE Marked |
| Reset Actuator Type | Toggle Switch |
