Associated Spring Raymond - 10.67mm OD, 0.97mm Wire, 22.35mm Free Length, Compression Spring - 2.19 Lb Spring Rating, 29.36 N Max Work Load, Music Wire
Item #: 40938318
Brand: Associated Spring Raymond
Model #: C04200380880M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 10.67 |
| Outside Diameter (Decimal Inch) | 0.4200 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 2.1900 |
| Maximum Work Load (N) | 29.36000061 |
| Solid Height (mm) | 6-1/4 |
| Solid Height (Decimal Inch) | 0.2460 |
| Material | Music Wire |
| Wire Size (mm) | 0.97 |
| Wire Size (Decimal Inch) | 0.0380 |
