Grooving Insert: GCM2002GA H10, Solid Carbide Uncoated, Neutral, 2 mm Cutting Width, 20 mm Max Depth, Series GND
Item #: 38682738
Brand: Sumitomo
Model #: 18R7ANQ
Product Specifications
| Insert Style | GCM |
| Insert Size | 2002 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | H10 |
| Cutting Width (mm) | 2.00 |
| Maximum Depth of Cut (mm) | 20.00 |
| Insert Holding Method | Clamp |
| Cutting Height (mm) | 3.60 |
| Insert Hand | Neutral |
| Corner Radius (mm) | 0.20 |
| Corner Radius (Decimal Inch) | 0.0079 |
| Maximum Depth Of Cut Range (mm) | 20.00+ |
| Cutting Tool Application | Grooving |
| Series | GND |
| Relief Angle | 7 |
| Manufacturers Catalog Number | GCGN2002-GA-H10 |
| Chip Breaker | GA |
| Coating/Finish | Uncoated |
| Number Of Cutting Edges | 2 |
| Insert Thickness | 3.60 |
