Kennametal - 20mm, 15 Flute, Solid Carbide, 1mm Corner Radius End Mill - 166mm OAL, 36° Helix, 40mm LOC, Right Hand Cut
Item #: 38054672
Brand: Kennametal
Model #: 5957786
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Aluminum titanium nitride (AlTiN) is one of the most abrasive-resistant and hardest of the coatings. It is commonly used for machining aircraft and aerospace material, nickel alloys, stainless steel, titanium, cast iron and carbon steel.
| Product Specifications | |
|---|---|
| Mill Diameter (mm) | 20.00 |
| End Type | Corner Radius |
| Corner Radius (mm) | 1.000 |
| Corner Radius (Decimal Inch) | 0.0394 |
| Number of Flutes | 15 |
| Material | Solid Carbide |
| Finish/Coating | AlTiN |
| Length of Cut (mm) | 40.00 |
| Shank Diameter (mm) | 20.00 |
| Overall Length (mm) | 166.00 |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Helix Angle | 36 |
| Reach Length (mm) | 100.00 |
| Reach Length (Decimal Inch) | 3.9370 |
| Neck Diameter (mm) | 18.80 |
| Neck Diameter (Decimal Inch) | 0.7402 |
| Material Grade | KC643M |
| Additional Information | SAFE-LOCK Shank |
