Seco - KNUX160405 11 Grade TP1501 Carbide Turning Insert - Al2O3 Finish, 55° Parallelogram, 3/8" Inscr Circle, 3/16" Thick, 1/64" Corner Radius
Item #: 37202512
Brand: Seco
Model #: 18868
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | KNUX |
| Insert Size | 160405 |
| Material | Carbide |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Inscribed Circle (Inch) | 3/8 |
| Thickness (Inch) | 3/16 |
| Thickness (Decimal Inch) | 0.1874 |
| Corner Radius (Inch) | 1/64 |
| Corner Radius (mm) | 0.396 |
| Corner Radius (Decimal Inch) | 0.0197 |
| Manufacturer's Grade | TP1501 |
| Coating | Al2O3 |
| Chip Breaker | 11 |
| Rake | Negative |
| Relief Angle | 0 |
| Coating Process | Duratomic |
| Primary Workpiece Material | P |
| Secondary Workpiece Material | K |
| Included Angle | 55 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Insert Holding Method | Clamp |
| FullRadius | No |
| Shape | Parallelogram |
