Boston Gear - 12 Pitch, 2.667" Pitch Diam, 32 Tooth Spur Gear - 3/4" Face Width, 5/8" Bore Diam, 1.92" Hub Diam, 14.5° Pressure Angle, Steel
Item #: 36682219
Brand: Boston Gear
Model #: ND32A
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Spur Gear |
| Number of Teeth | 32 |
| Hub Diameter (Decimal Inch) | 1.9200 |
| Pitch Diameter (Decimal Inch) | 2.6670 |
| Bore Diameter (Decimal Inch) | 0.6250 |
| Material | Steel |
| Face Width (Decimal Inch) | 0.7500 |
| Pressure Angle | 14.5 |
| PSC Code | 3020 |
