Walter-Prototyp - 20mm, 4 Flute, Single End, Solid Carbide, 2mm Corner Radius End Mill - 104mm OAL, 50° Helix, Right Hand Flute, 32mm LOC, Right Hand Cut, 52mm Extended Reach
Item #: 36248169
Brand: Walter-Prototyp
Model #: 5905815
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
TiAlN/ZrN is a high performance multilayer specifically developed for machining steel. It's chemically resistant to emulsions and oils and is extremely effective in preventing built up edges.
| Product Specifications | |
|---|---|
| Mill Diameter (mm) | 20.00 |
| Mill Diameter (Decimal Inch) | 0.7874 |
| End Type | Corner Radius |
| Corner Radius (mm) | 2.000 |
| Corner Radius (Decimal Inch) | 0.0787 |
| Number of Flutes | 4 |
| Material | Solid Carbide |
| Finish/Coating | TiAlN/ZrN |
| Length of Cut (mm) | 32.00 |
| Length of Cut (Decimal Inch) | 1.2598 |
| Shank Diameter (mm) | 20.00 |
| Overall Length (mm) | 104.00 |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Helix Angle | 50.00 |
| Reach Length (mm) | 52.00 |
| Reach Length (Decimal Inch) | 2.0472 |
| Neck Diameter (mm) | 19.00 |
| Neck Diameter (Decimal Inch) | 0.7480 |
| Material Grade | A1207 |
| Single or Double End | Single |
| Length Type | Regular |
| Centercutting | Yes |
| Flute Direction | Right Hand |
| Mill Diameter Tolerance (mm) | h9 |
| Shank Diameter Tolerance (mm) | h6 |
| Extended Reach | Yes |
| Overall Length Tolerance (mm) | +2.00 |
| TIR Maximum (mm) | 0.01 |
