Walter-Prototyp - 16mm, 4 Flute, Single End, Solid Carbide, 3mm Corner Radius End Mill - 145mm OAL, 45° Helix, Right Hand Flute, 90mm LOC, Right Hand Cut
Item #: 36246973
Brand: Walter-Prototyp
Model #: 5588254
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Aluminum chromium nitride (AlCrN) has higher heat resistance than AlTiN. It is commonly used for machining aircraft and aerospace material, nickel alloy, stainless steel, titanium, cast iron and carbon steel.
| Product Specifications | |
|---|---|
| Mill Diameter (mm) | 16.00 |
| Mill Diameter (Decimal Inch) | 0.6299 |
| End Type | Corner Radius |
| Corner Radius (mm) | 3.000 |
| Corner Radius (Decimal Inch) | 0.1181 |
| Number of Flutes | 4 |
| Material | Solid Carbide |
| Finish/Coating | AlCrN |
| Length of Cut (mm) | 90.00 |
| Length of Cut (Decimal Inch) | 3.5433 |
| Shank Diameter (mm) | 16.00 |
| Overall Length (mm) | 145.00 |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Helix Angle | 45.00 |
| Material Grade | A1007 |
| Single or Double End | Single |
| Length Type | Extra Long |
| Centercutting | Yes |
| Flute Direction | Right Hand |
| Mill Diameter Tolerance (mm) | h9 |
| Shank Diameter Tolerance (mm) | h6 |
| Extended Reach | No |
| Overall Length Tolerance (mm) | +2.00 |
| TIR Maximum (mm) | 0.02 |
