Walter-Prototyp - 12mm, 4 Flute, Single End, Solid Carbide, 1mm Corner Radius End Mill - 150mm OAL, 30° Helix, Right Hand Flute, 12mm LOC, Right Hand Cut, 90mm Extended Reach
Item #: 36243384
Brand: Walter-Prototyp
Model #: 5529956
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Diamond is one of the hardest abrasive coatings. It is commonly used in grinding and polishing ceramic, stone and aluminum alloy.
| Product Specifications | |
|---|---|
| Mill Diameter (mm) | 12.00 |
| Mill Diameter (Decimal Inch) | 0.4724 |
| End Type | Corner Radius |
| Corner Radius (mm) | 1.000 |
| Corner Radius (Decimal Inch) | 0.0394 |
| Number of Flutes | 4 |
| Material | Solid Carbide |
| Finish/Coating | Diamond |
| Length of Cut (mm) | 12.00 |
| Length of Cut (Decimal Inch) | 0.4724 |
| Shank Diameter (mm) | 12.00 |
| Overall Length (mm) | 150.00 |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Helix Angle | 30.00 |
| Reach Length (mm) | 90.00 |
| Reach Length (Decimal Inch) | 3.5433 |
| Neck Diameter (mm) | 11.80 |
| Neck Diameter (Decimal Inch) | 0.4646 |
| Material Grade | A1007 |
| Single or Double End | Single |
| Length Type | Extra Long |
| Centercutting | Yes |
| Flute Direction | Right Hand |
| Mill Diameter Tolerance (mm) | h9 |
| Shank Diameter Tolerance (mm) | h5 |
| Extended Reach | Yes |
| Overall Length Tolerance (mm) | +2.00 |
| TIR Maximum (mm) | 0.01 |
