Sumitomo - DCMT21.51 ENK Grade AC830P Carbide Turning Insert - 55° Diamond, 1/4" Inscr Circle, 3/32" Thick, 1/64" Corner Radius
Item #: 35566264
Brand: Sumitomo
Model #: 19RBW4V
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | DCMT |
| Insert Size | 21.51 |
| Material | Carbide |
| Inscribed Circle (mm) | 6.35 |
| Inscribed Circle (Decimal Inch) | 0.2500 |
| Inscribed Circle (Inch) | 1/4 |
| Thickness (Inch) | 3/32 |
| Thickness (Decimal Inch) | 0.0940 |
| Corner Radius (Inch) | 1/64 |
| Corner Radius (Decimal Inch) | 0.0156 |
| Manufacturer's Grade | AC830P |
| Material Grade | C5/C5A/C6 |
| Chip Breaker | ENK |
| Hole Diameter (Decimal Inch) | 0.1100 |
| Relief Angle | 7 |
| Primary Workpiece Material | P; M |
| Included Angle | 55 |
| Insert Holding Method | Screw |
| Shape | Diamond |
