Sandvik Coromant - CNMX1911 PF Grade 4325 Carbide Turning Insert - TiCN/AI2O3/TiN Finish, 80° Diamond, 3/4" Inscr Circle, 11mm Thick, 4mm Corner Radius
Item #: 35009570
Brand: Sandvik Coromant
Model #: 6433957
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | CNMX |
| Insert Size | 1911 |
| Material | Carbide |
| Inscribed Circle (mm) | 19.05 |
| Inscribed Circle (Decimal Inch) | 0.7500 |
| Inscribed Circle (Inch) | 3/4 |
| Thickness (Decimal Inch) | 0.4331 |
| Thickness (mm) | 11.00 |
| Corner Radius (mm) | 4 |
| Corner Radius (Decimal Inch) | 0.1575 |
| Manufacturer's Grade | 4325 |
| Coating | TiCN/AI2O3/TiN |
| Chip Breaker | PF |
| Hole Diameter (mm) | 7.80 |
| Hole Diameter (Decimal Inch) | 0.3071 |
| ISO Number | CNMX 19 11 40-PF 4325 |
| Relief Angle | 0 |
| Coating Process | CVD |
| Included Angle | 80 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Series | T-Max P |
| Maximum Depth of Cut (mm) | 15.34 |
| Insert Holding Method | Pin & Clamp |
| Cutting Edge Style | Rounded |
| Shape | Diamond |
