De-Sta-Co - 450 Lb Inner Hold Capacity, Vert Mount, Air Power Hold-Down Toggle Clamp - G1/8 Port, 145 Max psi, 95° Bar Opening, 68.33mm Height Under Bar
Item #: 33894247
Brand: De-Sta-Co
Model #: 817-SE
Exact Tooling IR#: 04
Features and Benefits
Vertical mounts are designed with the toggle at 90 degrees. The cylinder is mounted in either a vertical position or a position that is perpendicular to the clamping bar.
| Product Specifications | |
|---|---|
| Power Type | Pneumatic |
| Mounting Orientation | Vertical |
| Holding Capacity - Inner (N) | 2000 |
| Holding Capacity - Inner (Lb.) | 450 |
| Height Under Bar (mm) | 68.33 |
| Height Under Bar (Decimal Inch) | 2.69 |
| Port Size | G1/8 |
| Bar Opening (Degrees) | 95 |
| Length Distance Between Mount Holes (mm) | 16.00 |
| Length Distance Between Mount Holes (Decimal Inch) | 0.6300 |
| Width Distance Between Mount Holes (mm) | 25.40 |
| Width Distance Between Mount Holes (Decimal Inch) | 1.0000 |
| Clamping Force - Inner (N) | 1608 |
| Clamping Force - Inner (Lb.) | 361 |
| Bar Extension (Decimal Inch) | 3.0400 |
| Bar Extension (mm) | 77.22 |
| Overall Open Length (mm) | 98.30 |
| Overall Open Length (Decimal Inch) | 3.87 |
| Overall Closed Length (mm) | 177.04 |
| Overall Closed Length (Decimal Inch) | 6.97 |
| Overall Closed Height (mm) | 190.75 |
| Overall Closed Height (Decimal Inch) | 7.51 |
| Outer Clamping Force (N) | 1005 |
| Outer Clamping Force (Lb.) | 226 |
| Maximum Air Pressure (psig) | 145.00 |
| Maximum Air Pressure (bar) | 10.00 |
| Mounting Hole Size (mm) | 6.86 |
| Mounting Hole Size (Decimal Inch) | 0.2700 |
| Bar Style | Solid |
| Bar End Type | Closed |
| Maximum Mechanical Advantage | 2.25:1; 4:1 |
| Sensor Compatibility | Round; T-Slot |
| Cylinder Bore Size (mm) | 32.00 |
| Cylinder Bore Size (Decimal Inch) | 1.2600 |
| Spindle Thread Size | 5/16; M8 |
| Maximum Operating Temperature (C) | 90.00 |
| Maximum Operating Temperature (F) | 194.00 |
| Minimum Operating Temperature (F) | 14.00 |
| Minimum Operating Temperature (C) | -10.00 |
| Includes | Bolt Retainer |
