Heli-Coil - Single Insert, 7/16-14 UNC, 1D, Stainless Steel Screw Locking Insert - 4-1/2 Free Coils, 7/16 Inch Overall Length, 0.526 to 0.551 Inch Outside Diameter, with Tang, Primer Free Coating, 304 Material Grade
Item #: 32886517
Brand: Heli-Coil
Model #: A3585-7CNPF438
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 7/16-14 |
| Overall Insert Length (Decimal Inch) | 0.4380 |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.5260 |
| Maximum Outside Diameter (Decimal Inch) | 0.5510 |
| Finish/Coating | Primer Free |
| Number of Free Coils | 4-1/2 |
| Maximum Locking Torque (In/Lb) | 100 |
| Minimum Break Away Torque (In/Lb) | 16.50 |
| Thread Standard | UNC |
| Material Grade | 304 |
