Kyocera - 50.8mm Cut Diam, 25.4mm Arbor Hole, 12.7mm Max Depth of Cut, 30° Indexable Chamfer & Angle Face Mill - 3 Inserts, XPMT 15T3 Insert, Right Hand Cut, 3 Flutes, Series FM
Item #: 32068025
Brand: Kyocera
Model #: 8601028
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Inch) | 0 |
| Cutting Diameter (mm) | 50.80 |
| Cutting Diameter (Decimal Inch) | 2.0000 |
| Arbor Hole Diameter (mm) | 25.40 |
| Arbor Hole Diameter (Inch) | 0 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Lead Angle | 30 |
| Overall Height (Decimal Inch) | 1.3440 |
| Insert Compatibility | XPMT 15T3 |
| Series | FM |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 12.70 |
| Maximum Depth of Cut (Decimal Inch) | 0.5000 |
| Number of Cutter Inserts | 3 |
| Insert Holding Method | Screw |
| Cutter Style | FM |
| Number of Flutes | 3 |
| Keyway Width (Decimal Inch) | 0.3750 |
| Cutting Direction | Right Hand |
| Overall Diameter (Decimal Inch) | 2.0000 |
| Complete Insert Compatibility | XPMT 15T3 |
