Barksdale - 0.5 to 30 PSI Adjustable Range, 2,000 Max psi, Diaphragm Piston Pressure Switch - 1/4 NPT Female, Screw Terminals, SPDT Contact, Anodized Al Wetted Parts, 2% Repeatability
Item #: 31034291
Brand: Barksdale
Model #: P1H-B30
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Maximum Adjustable Range | 30 PSI |
| Minimum Adjustable Range | 0.5 psi |
| Type | Diaphragm Piston Pressure Switch |
| Maximum Pressure Setting | 2000 psi |
| Thread Size | 1/4 |
| Thread Type | NPT Female |
| Electrical Connection | Screw Terminals |
| Amperage Rating | 10 Amp@125/250/480VAC; 2 Amp@600VAC; 0.05 Amp@125VDC |
| Repeatability | 2% |
| Contact Form | SPDT |
| Maximum Adjustable Range on Fall | 30 |
| Maximum Adjustable Range on Rise | 30 |
| Maximum Deadband | 2.00 |
| Maximum Setpoint Deadband | 2.00 |
| Maximum Temperature (C) | 74 |
| Maximum Temperature (F) | 165 |
| Minimum Deadband | 0.4 psi |
| Minimum Setpoint Deadband | 0.40 |
| Minimum Temperature (C) | -29 |
| Minimum Temperature (F) | -20 |
| Additional Information | Anodized Aluminum; BUNA-N Diaphragm |
