Iscar - 50mm Body Diam, Manual Single Cutter Boring Head - 60mm to 75mm Bore Diam
Item #: 30723183
Brand: Iscar
Model #: 4560112
Exact Tooling IR#: 04
Features and Benefits
Boring heads with a single cutter (single edge) are used for general purpose finishing and roughing operations. They may also be used where machine power is limited.
Integral shank boring heads have the shank built into the head.
| Product Specifications | |
|---|---|
| Type | Single Cutter Boring Head |
| Actuation Type | Manual |
| Body Diameter (mm) | 50.00 |
| Mount Type | Integral Shank |
| Shank Type | Modular Connection |
| Modular Connection Size | MB50 |
| Series | Itsbore |
| Minimum Bore Diameter (Decimal Inch) | 2.3622 |
| Minimum Bore Diameter (mm) | 60.00 |
| Maximum Bore Diameter (mm) | 75.00 |
| Maximum Bore Diameter (Decimal Inch) | 2.9528 |
| Projection (mm) | 87.00 |
| Projection (Decimal Inch) | 3.4252 |
