Iscar - 143.6mm Cut Diam, 40mm Arbor Hole, 19mm Max Depth of Cut, 65° Indexable Chamfer & Angle Face Mill - 6 Inserts, T465 LN.T 2212ZN.. Insert, Right Hand Cut, Series Helitang
Item #: 30707764
Brand: Iscar
Model #: 3106144
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 143.60 |
| Cutting Diameter (Decimal Inch) | 5.6535 |
| Arbor Hole Diameter (mm) | 40.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.5748 |
| Lead Angle | 65 |
| Overall Height (Decimal Inch) | 2.4803 |
| Overall Height (mm) | 63.00 |
| Insert Compatibility | T465 LN.T 2212ZN.. |
| Series | Helitang |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 19.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.7480 |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | T465 FLN-22ST |
| Hub Diameter (Decimal Inch) | 3.7402 |
| Hub Diameter (mm) | 95.00 |
| Keyway Width (mm) | 16.40 |
| Keyway Width (Decimal Inch) | 0.6457 |
| Cutting Direction | Right Hand |
| Maximum Insert Radius (Decimal Inch) | 0.0984 |
| Counterbore Diameter (Decimal Inch) | 2.2047 |
| Complete Insert Compatibility | T465 LNHT 2212ZN-R; T465 LNHT 2212ZNTL; T465 LNHT 2212ZNTR; T465 LNMT 2212ZNTR-CS |
