Square D - 60 Amp, 480Y/277 V, 3 Pole, Bolt On Miniature Circuit Breaker - Thermal Magnetic Trip, 18 kA Breaking Capacity, 14-6 (Aluminum Copper) AWG, 4.05 Inch Deep x 5.66 Inch High x 2.94 Inch Wide
Item #: 30044192
Brand: Square D
Model #: EDB34060
Exact Tooling IR#: 04
Features and Benefits
Thermal-magnetic tripping mechanisms are designed with both a bi-metal switch and an electromagnet. They perform as a thermal breaker for low level overloads and perform as a magnetic breaker for instantaneous tripping mechanism at high levels.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | Miniature Circuit Breaker |
| Amperage | 60 |
| Number of Poles | 3 |
| Breaking Capacity | 18 kA |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Lug |
| Mounting Type | Bolt-on |
| Voltage | 480Y/277 V |
| Wire Size (AWG) | 14-6 (Aluminum Copper) |
| Overall Depth (Decimal Inch) | 4.0500 |
| Overall Height (Decimal Inch) | 5.6600 |
| Overall Width (Decimal Inch) | 2.9400 |
| For Use With | NF Panelboard |
| Standards Met | CSA; HACR Rated; UL Listed |
