Turning Insert: CNMM866SN-R88 CTCP125, Polycrystalline Cubic Boron Nitride TiCN & Al2O3 Finish, Neutral, 0.0472″ Corner Radius, 60.0 ° N/A Triangle, Series CNMM
Item #: 26237073
Brand: Ceratizit
Model #: 76133584
Product Specifications
| Insert Style | CNMM |
| Insert Shape Code | C |
| Insert Size Code | 866 |
| Insert Shape | Triangle |
| Clearance Code | N |
| Tolerance Code | M |
| Insert Material | Polycrystalline Cubic Boron Nitride |
| Manufacturer Grade | CTCP125 |
| Hole Diameter (Decimal Inch) | 0.1500 |
| Maximum Depth of Cut (Decimal Inch) | 0.6496 |
| Inscribed Circle (Decimal Inch) | 0.3748 |
| Insert Holding Method | Clamp |
| Insert Hand | Neutral |
| Insert Thickness (Decimal Inch) | 0.1874 |
| Corner Radius (Decimal Inch) | 0.0472 |
| Included Angle | 60.0 |
| Relief Angle | 0 |
| Series | CNMM |
| Coating Process | CVD |
| Rake | Negative |
| Wiper Edge | No |
| Number Of Cutting Edges | 6 |
| Primary Workpiece Material | Cast Iron; Steel |
| Primary Workpiece Material Code | P; K |
| Secondary Workpiece Material | Stainless Steel |
| Secondary Workpiece Material Code | M |
| Ansi Code | CNMM866SNR88CTCP125 |
| Iso Code | CNMM 250924SN-R88 CTCP125 |
| Chip Breaker | R88 |
| Coating/Finish | TiCN; Al2O3 |
