Turning Insert: TPMT110304-PF GH730, Solid Carbide TiCNO Finish, Neutral, 60.0 ° N/A Triangle, Series TPMT
Item #: 20877585
Brand: Tungaloy
Model #: 6821017
Product Specifications
| Insert Style | TPMT |
| Insert Size Code | 110304 |
| Insert Shape | Triangle |
| Insert Material | Solid Carbide |
| Manufacturer Grade | GH730 |
| Hole Diameter (Decimal Inch) | 3.4000 |
| Maximum Depth of Cut (mm) | 1.50 |
| Inscribed Circle (mm) | 6.35 |
| Insert Holding Method | Screw |
| Insert Hand | Neutral |
| Insert Thickness | 3.18 |
| Corner Radius (mm) | 0.40 |
| Included Angle | 60.0 |
| Relief Angle | 11 |
| Series | TPMT |
| Coating Process | PVD |
| Rake | Positive |
| Wiper Edge | No |
| Number Of Cutting Edges | 3 |
| Primary Workpiece Material | Stainless Steel; Steel |
| Primary Workpiece Material Code | P; M |
| Ansi Code | TPMT110304PFGH730 |
| Iso Code | TPMT221-PF GH730 |
| Chip Breaker | PF |
| Coating/Finish | TiCNO |
